Features:
It's Wonderfully Split!
Flexible, scalable, and divided up in all the right ways: the TUF Gaming GT502 puts your prized hardware up front and holds your six with a stack of cooling options to slay thermals and express ultimate performance. Load up, lock in, and watch it thrive.
Dual-Chamber Chassis
Climate control
GT502 internals are divided into two chambers, allowing you to build clean and configure independent cooling zones for the CPU and GPU. Freely expand your rig and give system components the ideal environment to dish out frames and slice through workloads.
Hybrid Function Bracket
Chill or stow
A 360mm bracket rides in the rear chamber and can carry radiator and fan combos or three storage devices.
Vertical Graphics Card Mount
Comfortable on edge
Stand your graphics card up proud with an included vertical mount or slot it directly into the motherboard and banish sag with a bundled support bracket.
Tool-Free Side Panels
Finger-friendly restrictions
The TUF Gaming GT502 continues its builder optimizations with side panels that can be removed simply by pressing a button hidden on the rear of the chassis.
Panoramic View
Single-state peekaboo
Tempered glass panels at the front and side provide a tactfully tinted view of the main chamber, showcasing your build to own the room.
Front Panel High-Speed USB Type-C
Within arm’s reach
In addition to two USB-A ports, the TUF Gaming GT502 front panel features a USB 3.2 Gen 2 Type-C port ripe for transfer speeds up to 10 Gbps.
TUF Gaming-Style Woven Straps
Weave ho!
Two durable and detachable straps that can support up to 30 kg (66 lbs) make it much easier to move the chassis around even when it’s packed with hardware.
Fully Modular Design
Down to the skeleton
Whether you prefer a modest build or a fully-loaded battle station, the GT502 is ready. Most of its panels and mounts are removable to ease hardware installation – take it apart to your heart’s content then build it up in your ideal image.
Matching Cables and Handles
Coordinated style
The cables and handles of the GT502 White Edition are color-matched to its pristine exterior for a distinctive aesthetic.
Specifications:
| Product Name |
TUF Gaming GT502 |
| Case Size |
Mid Tower |
| Motherboard Support |
|
| Drive Bays |
4 x 2.5"/3.5" Combo Bay |
| Expansion Slots |
- 8
- 3 (additional vertical)
|
| Front I/O Port |
- 1 x headphone / Microphone
- 2 x USB 3.2 Gen1
- 1 x USB 3.2 Gen2 Type C
- LED Control Button
|
| Tempered Glass |
|
| Radiator Support (Top) |
- 120 mm
- 140 mm
- 240 mm
- 280 mm
- 360 mm
|
| Radiator Support (Rear) |
120 mm |
| Cooling Support (Top) |
|
| Cooling Support (Rear) |
1 x 120 mm |
| Maximum CPU Cooler Height |
163 mm |
| Maximum GPU Length |
400 mm |
| Maximum PSU Length |
200 mm |
| Removable Dust Filters |
|
| Dimensions |
285 x 450 x 446 mm |
| Weight |
11Kg |
| Warranty |
1 Year |
