Features:
- Supported ATX and Micro-ATX Back-connect motherboard.
- Supports 360 mm radiator on the top, side and bottom
- 270-degree panoramic tempered glass.
- Pre-installed with 3 x 120 mm ARGB Reverse-blade fan at the side and 1 x 120 mm ARGB fan at the rear.
- 1-to-4 ARGB-Fan control board.
- Synergize with a compatible MSI motherboard through bridging with a USB 20Gbps Type-C (20Gbps) port for high speed data transmission.
- Removable dust filter at the top, side and bottom being easily removed for cleaning.
- UNI front panel cable make your DIY process easier and create more possibilities to your system.
The MSI ARSENAL GAMING (MAG) series is engineered to give gamers the edge they need to dominate on the virtual battlefield. Inspired by the rugged durability and unwavering reliability of military-grade equipment, the MAG series is built to provide an unwavering defense in every gaming scenario.
However, MAG isn't just about performance; it's a design language that conveys ruggedness and toughness, embodying the very essence of the MAG style. For gamers who are determined to dominate their digital battlegrounds, the MAG series is here to stand with you, establishing the ultimate defense.
Chamfering Technique
Each piece of 4 mm tempered glass is cut at an angle to minimize every edge gap to make case appearance look more beautiful.
EASY TO INSTALL
The gaming case has many features that make the installation process all the easier.
Specifications:
| Product Name |
MAG PANO 100R PZ |
| Case Form Factor |
Mid Tower |
| Color |
White |
| Motherboard Form Factor Support |
Regular: ATX / Micro-ATX / Mini-ITX
Back-connect: ATX / Micro-ATX |
| I/O Ports |
1 x USB 20Gbps Type-C
2 x USB 5Gbps Type-A
1 x Audio-Out / Mic-in
1 x LED Switch Button
1 x Power Button |
| Drive Mount Support |
3 x 2.5”
2 x 2.5”/3.5” combo |
| Expansion Slots |
8 |
| Maximum GPU Length |
380 mm / 14.96 inches |
| Maximum CPU Cooler Height |
166 mm / 6.54 inches |
| Power Supply Support |
ATX |
| Maximum PSU Length |
200 mm / 7.87 inches |
| Fan Size Support |
Top: 3 x 120 mm / 3 x 140 mm
Front: NA
Rear: 1 x 120 mm
Side: 3 x 120 mm / 2 x 140 mm
Bottom: 3 x 120 mm / 2 x 140 mm / 2 x 160 mm |
| Pre-installed Fan Size |
Side: 3 x 120 mm
Rear: 1 x 120 mm |
| Pre-installed Fan Type |
Side: 3 x ARGB Reverse-blade
Rear: 1 x ARGB |
| Radiator Size Support |
Top: 120 / 240 / 360 mm
Front: NA
Rear: 120 mm
Side: 120 / 240 / 360 mm
Bottom: 120 / 240 / 360 mm |
| Dimensions (DxWxH) |
518.7 x 290 x 482 mm / 20.42 x 11.42 x 18.98 inches |
| Connection |
1x USB 3.2 Gen 2x2 Type-C
2x USB 3.2 Gen 1 Type-A
Mic In/ Audio Out
LED Switch Button
Power Button
|
| Warranty |
3 Years |
